DAYTONA VELONA
80mm Speedometer/Tachometer

The 80mm Speedometer/Tachometer is a large and feature-packed gauge for your motorcycle. With an outer diameter of 80mm, this gauge is easy to read and looks great on vintage custom motorcycles. The needle display speedometer features liquid crystal white LED lights, and the digital tachometer is able to detect ignition methods such as crank 1 rotation/1 ignition, 2 rotations/1 ignition, 1 rotation/2 ignition, and 1 rotation/30 pulse output (* Note 1). The gauge also includes a voltmeter, fastest memory function, maximum rotation speed memory, odometer, and two trip meters (TRIP1 and TRIP2).

In addition to its impressive speed and tachometer functions, the 80mm Speedometer/Tachometer also includes indicators for warning light, neutral, high beam, turn signal left, and turn signal right. The gauge features a spherical lens, stepping motor drive, and is compatible with DC 12V power supply only. It comes with an external operation switch connection terminal and a V-shaped stay bracket for easy installation, and has a thin stainless steel body with an outer diameter of 80mm. Trust in the versatility and reliability of the 80mm Speedometer/Tachometer to keep you informed about your motorcycle's performance.

Speedometer

Needle display with liquid crystal white LED lights

Tachometer

Digital, capable of detecting ignition methods like:

Crank 1 rotation/1 ignition
2 rotations/1 ignition
1 rotation/2 ignition
1 rotation/30 pulse output (* Note 1)

Additional Functions

Voltmeter
Fastest memory function
Maximum rotation speed memory
Odometer
Two trip meters (TRIP1 and TRIP2)

Indicator Features

Warning light
Neutral
High beam
Turn signal left
Turn signal right

Other Attributes

Spherical lens
Stepping motor drive
Compatibility with DC 12V power supply only
External operation switch connection terminal
V-shaped stay bracket for easy installation
Thin stainless steel body
Outer diameter: 80mm

Electric Speed/Tachometer 200MPH 80mm
